Factory Lead Time

36 Weeks

Mount

Chassis Mount, Screw

Mounting Type

Chassis Mount

Package / Case

LP4

Number of Pins

4

Diode Element Material

SILICON

Operating Temperature (Max)

150°C

Operating Temperature (Min)

-40°C

Number of Elements

1

Packaging

Bulk

Published

1999

JESD-609 Code

e1

Pbfree Code

yes

Part Status

IN PRODUCTION (Last Updated: 1 month ago)

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

4

ECCN Code

EAR99

Terminal Finish

TIN SILVER COPPER

Applications

ULTRA FAST SOFT RECOVERY

Terminal Position

UPPER

Terminal Form

UNSPECIFIED

Element Configuration

Common Cathode

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Diode Type

Standard

Current - Reverse Leakage @ Vr

2.5mA @ 1200V

Voltage - Forward (Vf) (Max) @ If

2.5V @ 500A

Case Connection

ISOLATED

Forward Current

450A

Voltage - DC Reverse (Vr) (Max)

1200V

Max Reverse Voltage (DC)

1.2kV

Average Rectified Current

450A

Number of Phases

1

Reverse Recovery Time

110 ns

Peak Reverse Current

2.5mA

Max Repetitive Reverse Voltage (Vrrm)

1.2kV

Peak Non-Repetitive Surge Current

5kA

Radiation Hardening

No

RoHS Status

RoHS Compliant
